Metallographic Cut-off Machine
LC-300Z
PRODUCT ADVANTAGES
This machine adopts a fully enclosed structure, with good sealing effect, safe and reliable;
This machine adopts a fast clamping device, which can clamp objects more quickly and accurately;
Dual gas spring device, balancing the weight of the upper cover, making it effortless to open and close the upper cover;
Dedicated cooling water tank for circulating coolant;
The main components such as the jaws and workbench are made of stainless materials, which have a long service life;
Large cutting range and transmission power;
Classification：
Benchtop Cut-off Machines
Keyword：
Metallographic Cutting Machine
Metallographic Cut-off Machine
LC-300Z
This machine adopts a fully enclosed structure, with good sealing effect, safe and reliable;
This machine adopts a fast clamping device, which can clamp objects more quickly and accurately;
Dual gas spring device, balancing the weight of the upper cover, making it effortless to open and close the upper cover;
Dedicated cooling water tank for circulating coolant;
The main components such as the jaws and workbench are made of stainless materials, which have a long service life;
Large cutting range and transmission power;
Classification：
Benchtop Cut-off Machines
Keyword：
Metallographic Cutting Machine
Product Description
Maximum cutting section | Φ85mm |
Grinding wheel specifications | 300*2*32 |
| Rotational speed | 2800r/min |
| Electric machinery | 2.2KW 380V 50HZ |
| Emergency braking device | Emergency stop switch |
| Cutting room lighting | Low voltage DC lighting |
| Cutting platform specifications | 210*208mm |
| Clamping device | Standard quick fixtures (one set on each side) |
| Cooling system | External circulating filtration water tank 40L, multiple adjustable water spray devices and cleaning water guns |
| Cutting mode | Manual cutting |
| Observation window | Explosion proof transparent engineering plastic |
| Size (Width X Depth X Height) | 720X725X670mm |
| Weight | 100Kg |
